TI - LM2596T-5.0 Switching Voltage Regulators 150 KHZ 3A TO-220-5

The LM2596T-5.0 is a voltage regulator integrated circuit (IC) designed to regulate a constant output voltage of 5.0 volts. The LM2596T-5.0 is part of the LM2596 series, which is manufactured by various semiconductor companies, including Texas Instruments.

Here are key features and characteristics of the LM2596T-5.0 voltage regulator:

1. Voltage Regulation:

   • The LM2596T-5.0 is specifically designed to provide a stable and regulated output voltage of 5.0 volts.

2. Adjustable Output:

   • While the LM2596T-5.0 is set to output 5.0 volts, the LM2596 series also includes adjustable versions that allow users to set the output voltage to different values within a specified range.

3. Voltage Input Range:

   • The LM2596T-5.0 can typically handle a range of input voltages. However, it's essential to stay within the specified input voltage limits for proper operation.

4. Switching Regulator:

   • LM2596T-5.0 is a switching voltage regulator, meaning it uses a switching mechanism to control the output voltage, offering higher efficiency compared to linear regulators.

5. Applications:

   • Common applications for the LM2596T-5.0 include powering electronic circuits, devices, or components that require a stable 5.0-volt supply. It is often used in various DIY electronics projects and as a power supply component.

6. Output Current:

   • The LM2596T-5.0 is rated for a specific maximum output current. The actual current capability depends on factors such as the input voltage, output voltage, and thermal considerations.

7. Thermal Protection:

   • The IC may include thermal protection features to prevent damage from overheating. This helps ensure the reliability and longevity of the voltage regulator.
